MIL-M-38510-176 Microcircuits, Digital, Cmos, Latches, Monolithic Silicon, Positive LogicThis specification covers the detail requirements for monolithic silicon, CMOS, logic microcircuits. Two product assurance classes and a choice of case outlines, lead finishes, and radiation hardness assurance RHA are provided and are reflected in the complete Part or Identifying Number PIN. For this product, the requirements of MIL-M-38510 have been superseded by MIL-PRF-38535 see 6.3.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22 - 23 - 24 - 25 - 26 - 27 - 28 - 29 - 30 - 31 - 32 - 33 - 34 - 35 - 36 - 37 - 38 - 39 - 40 - 41 - 42 - 43 - 44 - 45 - 46 - 47

MIL-M-38510/1768

Device type 01

RL = 200 kν ± 5% CL = 50 pF ± 5%

(includes wiring and probe capacitance)

NOTES:

1. The pulse generator has the following characteristics:

VGEN = VDD ±1.0%, tPH = 1.0 ±0.1 μs, tr = tf ≤ 20 ±2 ns and PRR = 100 kHz.

2. See table III for complete terminal conditions.

FIGURE 4. Switching time test circuit and waveforms - Continued.
