MIL-M-38510/1238
Device type 01
Case I
TEST CIRCUIT
RL = 1 kν ± 5%
CL = 100 pF ± 5%
(Includes wiring and probe capacitance.)
NOTES:
1. The pulse generator has the following characteristics:
VGEN = 4 V, tTHL and tTLH ≤ 20 ns.
2. See table III for complete terminal conditions.
FIGURE 9. Switching time test circuits and waveforms - Continued.
15
